YGS Series · 700 bar
YGS24-20-700 Liquid-Driven Hydrogen Compressor
Electric-hydraulic compression to 700 bar (70 MPa) at 24 Nm³/h — an integrated, low-noise cabinet proven in 70 MPa storage filling and small refueling applications.
Technical Specifications
Key Features
Meets the pressure standard for vehicle-grade hydrogen storage and 70 MPa refueling.
Compressor and hydraulic power pack in one enclosure — minimal on-site installation.
Quiet enough for indoor and populated-area installation.
Using hydrogen refueling nozzles and hoses from WEH, a top-tier German brand, ensures safety.
Typical Applications
Where the YGS24-20-700 is working
01
Hydrogen car refueling
Direct to vehicle-grade pressure. Fill 70 MPa hydrogen storage cylinders from standard tube-trailer inlet pressure, with automatic pressure control.
02
Small & Distributed Refueling
A compact refueling core. The low-noise integrated cabinet fits small stations and demonstration sites where space and noise matter.
03
Miniature chemical plant
Convenient integrated equipment for easy pressurization in chemical plants
04
Hydrogen Energy Demonstration
Ready for showcase projects. Standard 230 V supply and minimal civil work make the YGS ideal for pilot and demonstration deployments.
Frequently Asked Questions
Yes. 700 bar output is exactly the pressure class required for 70 MPa vehicle-grade storage systems.
0.5–3.5 MPa, compatible with standard hydrogen tube trailers and storage bundles.
No. A level floor, 230 V power supply and ventilation are all it takes.
Tell us your inlet pressure, target pressure, voltage, flow and application — our engineers will select the right model. Contact us for a quotation.
Need a Quote or Technical Proposal?
Send us your inlet pressure, target pressure and flow — our engineers will respond with a tailored solution.
